Controlled Orbital Mixing for Laboratory Applications
The Orbital Shaker is a laboratory instrument designed for uniform mixing of samples through controlled orbital motion. It provides adjustable speed and timing functions, supporting consistent agitation for a range of laboratory applications.
Available in multiple configurations, it accommodates different vessel types and enables parallel sample processing.
| Product Type | Orbital shaker |
|---|---|
| Model | OS-20, OS-20Pro |
| Motion Type | Orbital (circular) |
| Speed Range | 40–200 RPM |
| Orbit Diameter | 20 mm |
| Maximum Load | 2 kg |
| Tray Options | Flat tray (268 × 268 mm), Universal tray (320 × 320 mm) |
| Timer Range | Up to 19 h 59 min (OS-20); up to 23 h 59 min (OS-20Pro) |
| Motor Type | DC motor (OS-20); brushless DC motor (OS-20Pro) |
| Protection Class | IP21 |
| Operating Conditions | 5–40 °C, ≤80% RH (OS-20); -5–40 °C, ≤80% RH (OS-20Pro) |
| Voltage | AC 100–240 V, 50/60 Hz |
| Applications | Cell culture, chemical mixing, laboratory use |
| Documentation | Certificate of Conformity (CoC) available upon request |
